Urtopia Carbon Joy E-Bike (Low Handlebar)
Urtopia Carbon Joy E-Bike (Low Handlebar)
The fat-tyre carbon cruiser, set up with a low-rise bar for a more athletic position.
| 500WMotor · 750W peak | 70 miMax range | 20″ x 3.0″Fat tyres | 45 lbNet weight |
Overview
This is the Carbon Joy fitted with a low-rise handlebar. Mechanically it is the same bike — carbon frame, 500W rear hub, 529.2Wh Samsung pack, 20″ x 3.0″ puncture-proof fat tyres — but the bar drops your hands and shifts your weight forward into a more active, sportier stance.
A 500W rear hub peaking at 750W with 60 N·m of torque moves it briskly and climbs well, and the removable 529.2Wh Samsung pack covers about 70 miles across four assist modes. The two-stage seatpost and 0–60° adjustable stem give a wide fit range, from 4’11″ to 6’3″.
What stands out
Low-rise handlebar
The lower bar puts more weight over the front wheel, sharpens steering response and makes the bike feel faster and more planted at speed.
Fat tyres without the fat weight
Kenda 20″ x 3.0″ puncture-proof rubber on thru-axles gives you sand, gravel and kerb capability. The carbon frame keeps the total at 45 lb.
Brake-sensing rear light
The rack-mounted tail light brightens under braking, and the hydraulic discs cut motor power the moment you pull a lever.
Two-stage seatpost
100 mm of inner and 120 mm of outer adjustment covers a very wide range of rider heights, which makes it a practical bike to share.
529.2Wh Samsung pack
Removable and UL 2271 certified, with a 3.5 hour recharge and four assist modes: Eco, Tour, Boost and Turbo.
Technical specifications
| General | |
| Model | Carbon Joy E-Bike (Low Handlebar) |
| Frame material | Carbon fiber frame |
| Net weight | 45 lb without accessories |
| Range | Up to 70 miles |
| Top speed | 20 mph as delivered, 25 mph once unlocked |
| Total weight limit | 330 lb |
| Rider height | 4’11″ – 6’3″ |
| Brakes | Hydraulic disc with power cut-off sensor |
| Wheels and tyres | Kenda 20″ x 3.0″ puncture-proof fat tyres, thru-axle |
| Water resistance | IP65 |
| Class | Class 2 |
| E-bike system | |
| Motor | 500W rear hub, 750W peak, 60 N·m |
| Battery | 529.2Wh Samsung lithium-ion, removable, UL 2271 |
| Throttle | Yes, up to 20 mph |
| Pedal assist | 4 levels: Eco, Tour, Boost, Turbo |
| Charger | 3.5 hour fast charger |
| Sensor | Torque sensor |
| Lights | Front external light, 30 lux; rack-mounted rear light with brake sensing |
| Drivetrain | |
| Chainring | 50T |
| Crankset | Aluminium alloy, 152 mm |
| Cassette | 12–32T, 8-speed |
| Chain | Shimano 8-speed |
| Rear derailleur | Shimano 8-speed |
| Shifter | 8-speed trigger |
| Pedals | PP, 103 x 84 x 24 mm |
| Cockpit | |
| Handlebar | Aluminium low-rise bar, stem extender adjustable 0–60° |
| Fork | Suspension fork, 50 mm travel with preload adjustment |
| Grips | PU leather |
| Saddle | Comfort saddle, 255 x 222 x 104 mm |
| Seatpost | Aluminium alloy, two-stage: Ø30.9 mm inner / Ø34.9 mm outer, 100 mm and 120 mm adjustment |
| Shipping | |
| Shipping weight | 60 lb (bike plus packaging) |
In the box
- Urtopia Carbon Joy e-bike, 95% pre-assembled
- Fast charger and power cable
- Two smart keys
- Assembly tool kit and mounting hardware
- Quick-start guide and 2-year warranty card
Shipping weight 60 lb (bike plus packaging). Range figures are manufacturer estimates measured with a 180 lb rider in the lowest assist mode on flat ground; real-world range varies with rider weight, terrain, tyre pressure, temperature and assist level. Class settings and top speed must comply with local regulations. Sold and serviced by All Gadget World, an authorised Urtopia dealer — 2-year manufacturer warranty included.
